Pipeviz

Easy, elegant lineage from a single .json

An open source JSON spec for lineage. Declare your pipelines, get beautiful graphs.

{
  "pipelines": [{
    "name": "etl-job",
    "input_sources": ["raw_events"],
    "output_sources": ["cleaned_events"]
  }]
}

Stack Agnostic

SQL, Spark, Kafka, APIs, shell scripts. Just JSON.

Zero Dependencies

One HTML file. No backend, no build step. Host anywhere.

Federated

Each team owns their JSON. Merge with jq for the org-wide view.

Column-Level Lineage

Track field-level provenance. See where each attribute comes from.

How it works

Define

Write a pipeviz.json describing your pipelines and data sources

Load

Drop your file here, or host both files together on any static server

Explore

Click through the graph, trace dependencies, export DOT for other tools

Superpowers

Each pipeline declares what it reads and writes. Pipeviz stitches these into a complete graph. From there, you get some superpowers for free:

Parallelize backfills by topologically sorting nodes into stages. Independent pipelines run together.

Detect circular dependencies before they break your backfill. Cycles shown in red.

Handle diamond dependencies correctly. Each node runs only after all its parents complete.

Trace blast radius downstream from any node. Know exactly what breaks.

Export to Mermaid and embed diagrams in CI/CD, PRs, or docs.

Serve via API with the built-in Clojure webserver. Query your graph programmatically.

Build MCPs on top of the API. Let LLMs query and reason about your lineage.

Why

Other solutions ask for a lot. OpenLineage/Marquez need agents, a metadata store, scheduler integration. Atlas wants a governance platform. dbt couples you to their framework. Pipeviz asks for one JSON file.

Why Clojure

Pipeviz is written in Clojure/ClojureScript, a Lisp that runs on the JVM and compiles to JavaScript, for two main reasons:

•

Code-as-data. Like Clojure, Pipeviz espouses the code-as-data philosophy: 100 functions operating on one data structure vs 10 functions on 10 structures. This style is well suited to spec validation, transformation, and extensibility.

•

No required persistence layer. Clojure is homoiconic. Your lineage graph is just an EDN map. Even when running Pipeviz as a server, you can REPL into a live instance, inspect state, redefine functions on the fly, and add your own hooks and validations that update your graph (without a DB).

Tip: Auto-load a config with ?url=https://yoursite.com/pipeviz.json

Load a configuration to see your pipelines

Load a configuration to see your datasources

Legend

■ = Pipeline

● = Data Source

▣ = Group

□ = Cluster

Node Details

Legend

▢ = Data Source

· = Attribute

→ = Derived from

Planner

Select pipelines to see the execution plan

Export

Export your graph as JSON, Mermaid, or DOT format

Load a configuration to see the export...

Load a configuration to see statistics.

Merging Pipeviz Configs

When your data platform spans multiple teams or repositories, you can maintain separate config files and merge them into a single Pipeviz config using jq.

Basic Merge (Two Files)

Combine pipelines and datasources from two config files:

jq -s '{
  pipelines: (.[0].pipelines + .[1].pipelines),
  datasources: (.[0].datasources + .[1].datasources)
}' team_a.json team_b.json > combined.json

Merge Multiple Files

Merge all *.pipeviz.json files in a directory:

jq -s '{
  pipelines: [.[].pipelines[]] | unique_by(.name),
  datasources: [.[].datasources[]] | unique_by(.name)
}' configs/*.pipeviz.json > combined.json

Merge with Deduplication

When configs might have overlapping definitions, dedupe by name (last write wins):

jq -s '{
  pipelines: (
    [.[].pipelines[]] | group_by(.name) | map(last)
  ),
  datasources: (
    [.[].datasources[]] | group_by(.name) | map(last)
  )
}' *.json > merged.json

Smart Prefix (Only on Collision)

Only add prefixes when names actually collide:

# Find colliding names, prefix only those
jq -s '
  [
    (.[0].pipelines | map(. + {_src: "a"})),
    (.[1].pipelines | map(. + {_src: "b"}))
  ] | add
  | group_by(.name)
  | map(
      if length > 1 then
        map(.name = ._src + "_" + .name)
      else . end
    )
  | add
  | map(del(._src))
' team_a.json team_b.json

Self-Hosting Pipeviz

Run a server that serves your config as a live dashboard.

Quick Start

Run the server with your config file:

# Start server on port 3000 with your config
clj -M:server 3000 path/to/your-config.json

Then open http://localhost:3000 in your browser.

Server Options

# Default port (8080) with config
clj -M:server path/to/config.json

# Custom port
clj -M:server 3000 path/to/config.json

# Multiple configs (merged automatically)
clj -M:server 3000 team_a.json team_b.json

REPL-Driven Development

Connect to the nREPL for live exploration and extension:

# Start shadow-cljs in watch mode
npx shadow-cljs watch app

# Connect to the REPL from another terminal
npx shadow-cljs cljs-repl app

The REPL gives you live access to the running app state. You can modify the graph, test analysis functions, or prototype new features without restarting.

Extending the Server

The server exposes a simple HTTP API. Add custom endpoints in src/pipeviz/server/main.clj:

;; Example: Add a custom analysis endpoint
(defn custom-handler [config]
  (fn [req]
    (case (:uri req)
      "/api/custom" {:status 200
                     :headers {"Content-Type" "application/json"}
                     :body (json/write-str (analyze config))}
      nil)))

OpenAPI Spec

The server includes an OpenAPI specification at resources/openapi.json:

# Endpoints documented in the spec:
GET /api/config      # Returns the loaded Pipeviz config
GET /api/health      # Health check endpoint

Use this spec with Swagger UI or to generate API clients.

Production Deployment

Build a standalone bundle for deployment:

# Build optimized JS bundle
npx shadow-cljs release release

# Bundle into single HTML file
./scripts/bundle.sh

# Output: dist/pipeviz.html (single-file, no server needed)

The bundled pipeviz.html is a single file with all JS/CSS inlined. Perfect for hosting on GitHub Pages, S3, or embedding in internal tools.

Pipeviz JSON Spec

Only pipelines is required. Clusters and datasources are auto-created when referenced.

Root

Field	Type	Required	Description
`pipelines`	array	Yes	Jobs that transform or move data
`datasources`	array	No	Tables, files, streams, APIs
`clusters`	array	No	Groups for visual organization

{
  "clusters": [...],
  "pipelines": [...],
  "datasources": [...]
}

Pipeline

Field	Type	Required	Description
`name`	string	Yes	Unique identifier
`description`	string	No
`input_sources`	array	No	Datasources read from
`output_sources`	array	No	Datasources written to
`upstream_pipelines`	array	No	Pipeline or group names (orange edges)
`cluster`	string	No	Cluster name
`group`	string	No	Collapse into group node
`schedule`	string	No	Free text
`tags`	array	No
`links`	object	No	name to URL
`duration`	number	No	Runtime in minutes (for critical path)
`cost`	number	No	Cost per run (for spend analysis)

{
  "name": "user-enrichment",
  "description": "Enriches user data with events",
  "input_sources": ["raw_users", "events"],
  "output_sources": ["enriched_users"],
  "upstream_pipelines": ["data-ingestion"],
  "cluster": "user-processing",
  "group": "etl-jobs",
  "schedule": "Every 2 hours",
  "duration": 45,
  "cost": 12.50,
  "tags": ["user-data", "ml"],
  "links": {
    "airflow": "https://...",
    "docs": "https://..."
  }
}

Datasource

Auto-created when referenced. Define explicitly to add metadata.

Field	Type	Required	Description
`name`	string	Yes	Unique identifier
`description`	string	No
`type`	string	No	snowflake, postgres, kafka, s3...
`owner`	string	No
`cluster`	string	No
`tags`	array	No
`metadata`	object	No	Arbitrary key-value
`links`	object	No	name to URL
`attributes`	array	No	Column-level lineage

{
  "name": "raw_users",
  "description": "Raw user data from prod",
  "type": "snowflake",
  "owner": "data-team@company.com",
  "cluster": "user-processing",
  "tags": ["pii", "users"],
  "metadata": {
    "size": "2.1TB",
    "record_count": "45M"
  },
  "links": {
    "snowflake": "https://...",
    "docs": "https://..."
  }
}

Cluster

Auto-created when referenced. Define explicitly for nesting.

Field	Type	Required	Description
`name`	string	Yes	Unique identifier
`description`	string	No
`parent`	string	No	Parent cluster for nesting

{
  "name": "realtime",
  "description": "Real-time processing cluster",
  "parent": "order-processing"
}

Attribute Lineage

Add attributes to a datasource. Supports nesting for structs/objects. Reference upstream with source::attr or source::parent::child.

Field	Type	Required	Description
`name`	string	Yes	Column/field name
`from`	string or array	No	Upstream refs
`attributes`	array	No	Nested child attributes

{
  "name": "enriched_users",
  "attributes": [
    { "name": "user_id", "from": "raw_users::id" },
    {
      "name": "location",
      "from": "raw_users::address",
      "attributes": [
        { "name": "city", "from": "raw_users::address::city" },
        { "name": "zip", "from": "raw_users::address::zip" }
      ]
    }
  ]
}

Full Example

{
  "clusters": [
    { "name": "etl", "description": "ETL pipelines" }
  ],
  "pipelines": [
    {
      "name": "user-enrichment",
      "description": "Enriches user data with events",
      "input_sources": ["raw_users", "events"],
      "output_sources": ["enriched_users"],
      "cluster": "etl",
      "schedule": "Every 2 hours",
      "tags": ["user-data"],
      "links": { "airflow": "https://..." }
    }
  ],
  "datasources": [
    {
      "name": "raw_users",
      "type": "snowflake",
      "owner": "data-team@company.com",
      "attributes": [
        { "name": "id" },
        { "name": "first" },
        { "name": "last" }
      ]
    },
    {
      "name": "enriched_users",
      "type": "snowflake",
      "attributes": [
        { "name": "user_id", "from": "raw_users::id" },
        { "name": "full_name", "from": ["raw_users::first", "raw_users::last"] }
      ]
    }
  ]
}

Edge Types

Color	Source	Description
Gray →	`input_sources` / `output_sources`	Data flow through datasources
Orange →	`upstream_pipelines`	Direct pipeline dependency
